Diamond Mowers
The Diamond Mowers family has been innovators in this industry for over 40 years. We are not an assembly shop like our competitors. We design and manufacture our products, from the smallest parts to the largest. This strategy allows us to control quality at every step of the process. From the beginning, we have never wavered in our efforts to continually improve our products.
Our 100% satisfaction guarantee and our 3-day parts shipping guarantee are unprecedented in this industry. At Diamond Mowers, your parts will ship within 3 days — or your parts and the shipping are free. Many companies talk about their customer service — we guarantee it.
Diamond® Boom Movers
Boom Mowers
|
|
|
|
|
|
|
| Side fold booms available in 19 ft, 21 ft or 23 ft |
|
|
| Rear Cradle Booms available in standard duty at 22 ft and 23 ft |
|
|
| Rear Creade Booms available in heavy duty at 23, 25, 28 and 30 ft |
|
|
The Dx2 Mainframe
- Increases utilization of tractor
- Accepts side attachments with boom in stow
- Accepts side rotary or flail attachments
- Attachments changed in 30 minutes or less
- Hydraulic Actuator comes standard with Dx2
|
|
3-Point Hitch Boom Mowers
|
|
|
|
|
|
|
| |
14' STD |
16' STD |
17' HD |
20' HD |
| Hitch |
Cat II or III |
Cat II or III |
Cat II or III |
Cat II or III |
| PTO |
540 |
540 |
1,000 |
1,000 |
| PTO HP |
60 |
60 |
90 |
90 |
| Min. Tractor Wt |
4,500 |
6,000 |
10,500 |
11,500 |
| Heads |
40" Rotary or 42" Flail |
40" Rotary or 42" Flail |
50" Rotary or 44" Flail |
50" Rotary or 44" Flail |
| Wt. w Rotary Head |
2440 lbs |
2506 lbs |
3095 lbs |
3145 lbs |
| Wt. w Flail Head |
2493 lbs |
2589 lbs |
3314 lbs |
3364 lbs |
Diamond® Rotary Mowers
Rotary Mowers
|
|
Side Mount Rotary Mowers
|
|
| Side cutter |
Rear cutter |
| Cutter Width 30" or 72" |
Cutter Width 60" |
| Cutter Head weight 60"/1,050 lbs |
Cutter head weight 1,600 lbs |
|
|
| Total Cutting widths: |
|
| 120" total cut - 60" side with 60" rear deck |
|
| 132" total cut - 72" side with 60" rear deck |
|
Diamond® Flail Mowers
FM Series - Flail Mowers
|
|
Heavy Duty Twin Flail Mowers
|
|
|
|
|
| Side Mounted Flail |
Rear-Mounted Flail |
|
|
|
| Cutter assembly - Hyd driven 2,400 rpm |
Cutter assembly - PTO driven |
|
|
|
| Cutter head 3/16", 1/2" dive side, 1/2" carrier side |
Cutter head 3/16", bonnet, 1/2" side wall |
|
|
|
| Cutter heads and weight: 60" - 1040 lbs and |
Cutter heads and weight: 90" -1442 & 102" |
|
|
|
| 75" - 1146 lbs |
and 1500 lbs |
|
|
|
| Pump is gear type with cast steel housing rated |
65 hp drive shaft; 90 hp constant; |
|
|
|
| at 98 hp |
135 hp intermittent rated gear box |
|
|
|
| Motor is gear type with cast steel housing rated at |
Three Point Hitch Mounting Category II |
|
|
|
| 74 hp |
Transmission Drive |
|
|
|
Rear PTO Flail Mowers
|
|
|
|
|
|
|
| Heavy Duty Rear PTO Flail Mowers |
|
|
|
|
| All Purpose knives are 6 gauge thickness - 1 3/4 " x 4 5/8" long |
|
|
|
| (Heavy Duty Size / Mower Options for all 540 PTO PTO) |
|
|
|
| * 90" Heavy Duty Rear Flail - Center/ Off-Set Mower |
|
|
|
|
| * 102" Heavy Duty Rear Flail - Center / Off-Set Mower |
|
|
|
|
|
|
|
|
|
| Standard Duty Rear PTO Flail Mower |
|
|
|
|
| Cutting shaft shall have your choice of all purpose, self cleaning, reversible knives or |
|
|
|
| smooth cutting knives |
|
|
|
|
| Types: 74", 88" or 96" standard rear flail mowers |
|
|
|
|
Triple Gang Flail Mowers
|
|
|
|
|
|
|
| Side Mounted Flail |
Rear-Mounted Flail |
|
|
|
| Cutter Assembly - Hyd Driven 1,800 RPM |
Cutter Assembly - PTO Driven |
|
|
|
| Designed to cut grass and brush up to 2" |
Designed to cut brush up to 2" |
|
|
|
| Cutter Head 2/16" bonnet, 1/2 sidewalls |
Cutter Assembly - PTO Driven |
|
|
|
| Cutter heads width and weight - 60" - 1040 lbs & |
Cutter heads width and weight - 90" - 1442 |
|
|
|
| 75" - 1146 lbs; 90" - 1290 lbs |
& 102" - 1500 lbs |
|
|
|
Rear Swing Flail Mowers
|
|
|
|
|
|
|
| Diamond RSF Mower Features |
|
|
|
|
| * Ability to swing out past the rear tire of most tractors |
|
|
|
| * Mows at a 50° down angle |
|
|
|
|
| * Mows at a 90° down angle |
|
|
|
|
| *Get finished cut in hard to reach places with side shift and drop |
|
|
|
| Diamond RSF Specs |
|
|
|
|
| 75" Heavy Duty Rear Swing Flail |
74" Standard Duty Rear Swing Flail |
|
|
|
| 540 PTO required |
540 PTO required |
|
|
|
| 75 HP required |
50 HP required |
|
|
|
| 9,500 lb tractor minimum |
7,000 lb tractor minimum |
|
|
|
| 2 tractor hydraulic remotes reqired |
2 tractor hydraulic remotes required |
|
|
|
| Cat II hitch required |
Cat II hitch required |
|
|
|
Diamond® Flexwing Mowers
Flexwing Mowers
|
|
|
|
|
| Model |
PTO required |
|
| 12' Flexwing |
540 |
|
| 10' Flexwing |
1000 |
|
| 15' Flexwing |
1000 |
|
| 10' Hydraulic Flexwing |
1000 |
|
| 15' Hydraulic Flexwing |
1000 |
|
|
